350pro

描述

cmThe LSF-350pro foot type measuring instrument is the latest mode introduced by the company simultaneous measurement of both feet at the same time. 3D scanning of human foot type and shoe last type, collecting high precision foot type and shoe last type 3D data, and generate 60 sets of personalized parameters, support uploading and downloading, which widely be used in the footwear industry and medical rehabilitation.

Fast scanning speed:
Both feet scanning 15-20s

High measurement precision:
Standard error<0.5mm

Generate STL data:
Directly generate STL triangle mesh data, can be used directly for 3D printing.

Foot data collection:
Automatically extract several characteristic parameters of the foot type- 60 sets and generate measurement reports, data analysis can be performed on single section of the foot type.

Foot type evaluation:
Evaluation of the internal and external valgus arch deformation.



Package(two parts):

1*.host:157*46*47cm

2.Acessor:120*85*58cm

G.W:122kg         N.W:101kg
